Description
Electric Actuators
Electric actuators
IBL-1700 series are reversing proportional motors used to operate dampers or valves in Electric Modulating Circuits.
Product Overview
Electric actuators are designed to meet the requirement of damper control, valve control applications where it is generally required to drive the load through less than one complete revolution either direction and to stop instantaneously at any point of the stroke. Such devices, sometimes also called as Modulating Motors are extensively used for Air-Conditioning, Boiler applications. FEATURES: 1.These are with line voltage or low voltage motors.
Technical Specifications
| Supply Voltage: | AC, Single Phase, 230V, 50Hz. |
|---|---|
| Power Consumption: | 20 Watts. |
| Stroke: | Factory set at 900, 1600 or 2700. (Field adjustment in steps of 30 is possible). |
| Stroke: | Auxiliary Switch (Optional): 2.5A, 250V, 50Hz, NO or NC. (Operated at only one fixed point). |
| Feedback Potentiometer: | 135Ω standard matched to stroke angle of either 900, 1600 or 2700. (The maximum permitted power dissipation for feedback potentiometer is 1W for 900, 1.5W for 1600, and 2W for 2700 stroke angle). |
| Torque-Speed capabilities: | Total gear ratio is adjusted at factory to obtain the following combination of torque and speed: |
About Interlabs
Interlabs, associated with International Biological Laboratories, supplies scientific, laboratory, educational and engineering equipment from India. The company identifies its history as dating to 1958. Contact Interlabs to confirm product details and supporting documentation for your requirement.
Request Product Information
Share your application and technical requirements for Electric actuators to discuss suitability, available configurations and a quotation.
Frequently Asked Questions
What is Electric actuators used for?
IBL-1700 series are reversing proportional motors used to operate dampers or valves in Electric Modulating Circuits.
What should I confirm before ordering Electric actuators?
Confirm the intended application, technical specifications, available configuration, accessories, documentation and delivery requirements with Interlabs.
