Description
Electro chemistry
Digital pH Conductivity & Temperature Meter
For Accurate Reliable & Fast Measurement of pH, Conductivity & Temperature in Laboratory FEATURES Highly Stable & Accurate 3 ½ Digit LED Display Rugged & Reliable design Cell constant adjustment facility Specifications GENERAL Digital Display 3 ½ digit LED Power 220V AC ± 10% 50Hz Dimensions 75 X 175 X 275 mm Weight 2.5.
Product Overview
Kg. (Approx.) PARAMETERS Range 0-14pH Resolution 0.01pH Accuracy ± 0.01 pH±1 digit Input Impedance >10 12 ohms Temperature Compensation 0 – 100oC (manual) Slope Correction 80 to 120% CONDUCTIVITY Range 0 to 20mS/cm in 2 ranges Accuracy ± 0.5% ± 1 digit Resolution 1µS/cm Oscillator 1KHz in-built Cell Constant 0.2 to 1.8 adjustable directly on digital display Temperature Compensation 0-50o C adjustable from Temp. Table at 25o C TEMPERATURE Range 0-100o C Resolution 0.1o C Accuracy ±0.2% ± 1digit Sensor RTD(PT-100) Accessories pH Combination Electrode, Cond.
Technical Specifications
| Digital Display | 3 ½ digit LED |
|---|---|
| Power | 220V AC ± 10% 50Hz |
| Dimensions | 75 X 175 X 275 mm |
| Weight | 2.5. Kg. (Approx.) |
| Range | 0-14pH |
| Resolution | 0.01pH |
| Accuracy | ± 0.01 pH±1 digit |
| Input Impedance | >10 12 ohms |
| Temperature Compensation | 0 – 100oC (manual) |
| Slope Correction | 80 to 120% |
| Range | 0 to 20mS/cm in 2 ranges |
| Accuracy | ± 0.5% ± 1 digit |
| Resolution | 1µS/cm |
| Oscillator | 1KHz in-built |
| Cell Constant | 0.2 to 1.8 adjustable directly on digital display |
| Temperature Compensation | 0-50o C adjustable from Temp. Table at 25o C |
| Range | 0-100o C |
| Resolution | 0.1o C |
| Accuracy | ±0.2% ± 1digit |
| Sensor | RTD(PT-100) |
| Accessories | pH Combination Electrode, Cond. Cell, Temperature Prode, Operation Manual, Dust Cover, pH Stand, 7 & 4 pH Bottles, Beaker. |
Features and Details
- Highly Stable & Accurate
- 3 ½ Digit LED Display
- Rugged & Reliable design
- Cell constant adjustment facility
About Interlabs
Interlabs, associated with International Biological Laboratories, supplies scientific, laboratory, educational and engineering equipment from India. The company identifies its history as dating to 1958. Contact Interlabs to confirm product details and supporting documentation for your requirement.
Request Product Information
Share your application and technical requirements for Digital pH Conductivity & Temperature Meter to discuss suitability, available configurations and a quotation.
Frequently Asked Questions
What is Digital pH Conductivity & Temperature Meter used for?
For Accurate Reliable & Fast Measurement of pH, Conductivity & Temperature in Laboratory FEATURES Highly Stable & Accurate 3 ½ Digit LED Display Rugged & Reliable design Cell constant adjustment facility Specifications GENERAL Digital Display 3 ½ digit LED Power 220V AC ± 10% 50Hz Dimensions 75 X 175 X 275 mm Weight 2.5.
What should I confirm before ordering Digital pH Conductivity & Temperature Meter?
Confirm the intended application, technical specifications, available configuration, accessories, documentation and delivery requirements with Interlabs.
